Conductivity: DC resistance ≤ 0.0012Ω/m (for 50mm² cross-section), ensuring low power loss and minimal heat generation.
• Flexibility: Bend radius ≥ 2× the connector width, enabling installation in narrow spaces and absorbing thermal expansion/contraction of equipment.
• Corrosion Resistance: Tin-plated surface (thickness ≥ 3μm) provides long-term protection against oxidation, salt spray, and humidity (passes 480h salt spray test per ASTM B117).
• Mechanical Strength: Tensile strength ≥ 150N (for 30mm² model), with crimped terminals ensuring pull-out force ≥ 200N (no loosening under vibration).
• Temperature Resistance: Operating temperature range: -40°C to 120°C, suitable for both low-temperature and moderate-heat environments.
